*Full CNC system.
*MPG Electronic hand wheel.
*Push button pendant station.
*Ball screws to Carriage Long Travel & infeed cross-travel (rack
drive on longer machines).
*Digital AC motors & drives.
*Work head mounted dresser.
*1 off three jaw chuck.
*1 off wheel hub.
*1 off tailstock.
*Rear vertical crosslide to mount optional equipment.
*Guarding
*Machine operating manual complete with electrical drawings and
foundation layout and standard mechanical parts catalogue.
*Certificate of conformity.
Capacity |
Dimensions |
Swing over slides |
49” (1245 mm) |
Distance between centres |
80” (2032mm) - 400" (10000mm) |
Maximum face width ground |
80” (2032mm) |
Minimum Component length |
6" (150mm) |
Minimum diameter ground (with 30"
wheel) |
1.574" (40mm) |
Wheel Size (maximum) |
30” x 12” bore x 3” wide |
Speed of axis |
Variable, electrical |
Work head speeds. Infinitely
variable |
0-400 rpm |
Work head hollow bore |
3.0709" (78 mm) |
Tailstock Morse taper |
5 |
Maximum work piece weight |
3000 Kgs |
Main Motor, grinding spindle (30"
wheel) |
18.5kw |
Floor area (approx.) |
5700mm x 2300mm |
Weight of machine (approx.) |
14,500 Kgs |
